I-DN800 DIN EN1092-1 PN40/PN6 Carbon Steel Weld Neck Flange
I-DN800 DIN EN1092-1 PN40/PN6 Carbon Steel Weld Neck Flange imele icandelo elibalulekileyo kwiinkqubo zemibhobho ezinkulu ezifuna ukuthembeka okuphezulu kwesakhiwo kunye nokusebenza okuthembekileyo kokutywina. Yenziwe ngokwemigangatho yaseYurophu, le flange yenzelwe ukusetyenziswa koxinzelelo oluphezulu kwiinkqubo zoshishino, idibanisa amandla aqinileyo entsimbi yekhabhoni kunye nomatshini ochanekileyo ukuqinisekisa ukusebenza kakuhle kwiimeko zenkonzo ezifuna amandla.
IINKCUKACHA
| Igama lemveliso | I-Lap joint/I-flange ekhululekileyo |
| Ubungakanani | 1/2"-24" |
| Uxinzelelo | 150#-2500#,PN0.6-PN400,5K-40K |
| Umgangatho | ANSI B16.5,EN1092-1, JIS B2220 njl. |
| Isiphelo sestub | I-MSS SP 43, i-ASME B16.9 |
| Izinto eziphathekayo | Yenziwe ngentsimbi eshayinayo:A182F304/304L, A182 F316/316L, A182F321, A182F310S, A182F347H, A182F316Ti, 317/317L, 904L, 1.4301, 1.4307, 1.4401, 1.4571,1.4541, 254Mo njl. |
| Intsimbi yekhabhoni:A105, A350LF2, S235Jr, S275Jr, St37, St45.8, A42CP, A48CP, E24, A515 Gr60, A515 Gr 70 njl. | |
| Intsimbi engagqwaliyo ephindwe kabini:I-UNS31803, SAF2205, UNS32205, UNS31500, UNS32750, UNS32760, 1.4462,1.4410,1.4501 njl. | |
| Intsimbi yombhobho:I-A694 F42, A694F52, A694 F60, A694 F65, A694 F70, A694 F80 njl. | |
| I-alloy ye-nickel:inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H,C22, C-276, Monel400, Alloy20 njl. | |
| Ingxubevange yeCr-Mo:A182F11, A182F5, A182F22, A182F91, A182F9, 16mo3,15Crmo, njl. | |
| Isicelo | Ishishini lePetrochemical; ishishini leenqwelo moya kunye neenqwelo moya; ishishini lamayeza; umphunga wegesi; isityalo samandla; isakhiwo seenqanawa; unyango lwamanzi, njl. |
| Iingenelo | isitokhwe esilungeleyo, ixesha lokuhanjiswa ngokukhawuleza; ifumaneka kuzo zonke iisayizi, yenzelwe wena; umgangatho ophezulu |
Yakhiwe ngentsimbi yekhabhoni ye-premium P265GH, le flange yentamo ye-weld inika iipropati ezibalaseleyo zoomatshini kubandakanya amandla amancinci okuvelisa angama-265 MPa kunye namandla okutsalwa angama-410-530 MPa. Ulwakhiwo lweekhemikhali olulawulwa ngononophelo lwezixhobo lubonelela ngokuthungwa okugqwesileyo, ukumelana nokugqwala, kunye nokuqina kumanqanaba obushushu ukusuka kwi--20°C ukuya kwi-+400°C.
IMIGANGATHO YODWALA
IINKCUKACHA ZEMVELISO UMBONO
Ihambelana ne-DIN EN1092-1 specifications, le flange ihlangabezana nemigangatho yomgangatho waseYurophu eqinileyo yezixhobo zoxinzelelo. Umgangatho we-PN40 ubonisa umthamo woxinzelelo oqhelekileyo we-40 bar kwi-120°C, ngelixa uhlobo lwe-PN6 lubonelela ngezisombululo ezingabizi kakhulu kwizicelo zoxinzelelo oluphantsi. Zombini iindlela zokucwangcisa zigcina ukuchaneka kobukhulu ngaphakathi kwamanqanaba okunyamezelana kwe-ISO, ukuqinisekisa ukuhambelana okungenamthungo neenkqubo zemibhobho yehlabathi.
UKUPHAKISHA NOKUPAKISHA
Iflange nganye ye-DN800 ifakwa kwiphakheji ebanzi yokukhusela eqala nge-VCI (Vapor Corrosion Inhibitor) coating ukuthintela ukugqwala ngexesha lokuhamba. Ukusonga kweplastiki okunzima kubonelela ngokhuseleko oluphambili, ngelixa i-foam esikiweyo ngokwezifiso ikhusela iindawo ezifakwe ngomatshini kunye nemingxunya yebholiti. Iikreyithi zokhuni ezinefreyimu eqinisiweyo ziqinisekisa ukuthembeka kwesakhiwo ngexesha lokuthunyelwa kwamanye amazwe, kunye nokusasazwa kobunzima obufanelekileyo kunye neendawo zokuphakamisa eziphawulwe ngokucacileyo ukuze ziphathwe ngokukhuselekileyo.
Inkqubo yethu yokuthumela ibandakanya iindlela ezikhethekileyo zokuphatha izinto ezinkulu. Iflange nganye ifumana uphawu lokuchongwa oluhlala luhleli oluquka umgangatho wezinto, inombolo yobushushu, kunye novavanyo loxinzelelo ukuze kube lula ukulawula impahla. Silungiselela ukulayisha izikhongozeli ukuze sisebenzise indawo kakuhle ngelixa siqinisekisa ukusasazwa kobunzima ngokufanelekileyo, kunye namaxwebhu aneenkcukacha zokuthumela aquka uluhlu lokupakisha, izatifikethi zobunzima, kunye nemiyalelo yokuphatha ehamba nokuthunyelwa ngakunye.
UVAVANYO
Iflange nganye idlula kwiiprotokholi zovavanyo oluqatha eziqala ngovavanyo lwe-ultrasonic ukuze kufunyanwe iziphene zangaphakathi. Ukuqinisekiswa kobukhulu becala kusetyenziswa iinkqubo zokulinganisa i-laser kuqinisekisa ukuthotyelwa kwe-EN1092-1 tolerances, ngelixa uvavanyo lwe-hydrostatic oluphindwe ka-1.5 uxinzelelo olulinganisiweyo luqinisekisa amandla okulawula uxinzelelo. Ukuqinisekiswa kwezinto kuquka uhlalutyo olupheleleyo lweekhemikhali kunye novavanyo lwepropathi yoomatshini kunye nokulandeleka okupheleleyo ukusuka kwizinto eziluhlaza ukuya kwimveliso egqityiweyo.
INKQUBO YEMVELISO
| 1. Khetha izinto zokwenyani | 2. Sika izinto ezikrwada | 3. Ukufudumeza kwangaphambili |
| 4. Ukubumba | 5. Unyango lobushushu | 6. Umatshini Onzima |
| 7. Ukubhola | 8. Ukuluka kakuhle | 9. Ukumakisha |
| 10. Uhlolo | 11. Ukupakisha | 12. Ukuhanjiswa |
ITYALA LENTSEBENZISWANO
Iprojekthi eseTurkey, iiflanges zisetyenziswa kwimibhobho yegesi yendalo. Zonke ezo flanges zivunyiwe yiTUV.
IPHEPHA LEDATHA YEFLANGE
1Ubukhulu beFlange kunye nokunyamezelana kwayo kufuneka kuhambelane ne-ASME B16.5.
2. Iiflanges maziveliswe ngokubumba.
3. Izixhobo mazihambelane nemigangatho ye-ASTM A105, ASTM A694 F65 kunye ne-ASTM A694 F70.
4. Iiflange ze-ASTM A694 F65 kunye ne-ASTM A694 F70 mazicinywe kwaye ziqiniswe.
5. Izatifikethi zovavanyo lwezinto kunye neengxelo zonyango lobushushu ziya kwenziwa zifumaneke kuhlolo lwe-TPI.
6. Iiflange zeWN mazibe neziphelo ze-bevel ezifikelela kwi-ASME B16.25.
7. Amaxabiso ovavanyo lweekhemikhali kunye noomatshini (impembelelo, isivuno, ukuxinana njl.njl.) kufuneka ahambelane nemigangatho enxulumene noko.
8. Zonke iindawo kufuneka zicocwe ngomatshini kwaye zifakwe ivarnish ngeoyile ecacileyo ukuthintela ukugqwala.
9. Ukumakisha kufuneka kuquka olu lwazi lulandelayo,
• Ububanzi (ixesha eliphela ngo-6”)
• Udidi loxinzelelo (oluphelelwa yi-150 LB)
• Udidi lwezinto (ukuphelelwa yi-ASTM A 105)
• Ubukhulu bodonga (ngaphandle kwe-4,78 mm)
• Inombolo yobushushu (iphelelwa lixesha 138413)
• Umgangatho wemveliso (ASME B16.5)
10. Izinto azinaziphene okanye ziqhekeke kumphezulu. Ukulungiswa kwee-welding akuvumelekanga ngokungqongqo.
11. Zonke iiflanges maziphakanyiswe ubuso (RF) kunye nomphezulu wokutywina. Umphezulu wokutywina kufuneka ube yiRa 3,2 – 6,3 µm (125 – 250 mic. inc.) acc. kwi-ASME B46.1.
12. Izinto kufuneka zipakishwe ukuze kuthintelwe umonakalo kwimishini, nakwindawo ezitywiniweyo.
13. Zonke izilinganiso mazibe kwimilinganiselo emihle (+). Ukunciphisa ukunyamezelana akuvumelekanga ngokupheleleyo.
14. Iibheveling zeFlange mazifakwe kwi-ASME B16.25.
15. Inkqubo yokuvelisa iya kuhlolwa nangaliphi na ixesha yi-TPI.
16. I-TPI ingathatha iisampulu kuyo nayiphi na into ukuze kwenziwe isampuli yovavanyo lweekhemikhali/yoomatshini.
17. Ingxelo yohlolo engenayo iya kuhlolwa yi-TPI.
| Into | Ubungakanani (Inch) | Iklasi yoXinzelelo | CS | Izinto eziphathekayo | Ubunzima (mm) | Indawo | Ubungakanani. |
| I-SORF | 12 | 150LB | 20 | A105 | - | IIFANGES ZETANKI | 48 |
| I-SORF | 8 | 150LB | 20 | A105 | - | IIFANGES ZETANKI | 32 |
| I-SORF | 3 | 150LB | 20 | A105 | - | IIFANGES ZETANKI | 32 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 14 | IIFANGES ZETANKI | 2 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 5.54 | IIFANGES ZETANKI | 4 |
| I-SORF | 20 | 150LB | 20 | A105 | - | IIFANGES ZETANKI | 6 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 5.54 | IIFANGES ZETANKI | 8 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 14 | IIFANGES ZETANKI | 8 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 16 | IIFANGES ZETANKI | 8 |
| I-SORF | 3 | 150LB | 20 | A105 | - | IIFANGES ZETANKI | 24 |
| I-SORF | 20 | 150LB | 20 | A105 | - | IIFANGES ZETANKI | 6 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 5.54 | IIFANGES ZETANKI | 8 |
| I-Flange, Intamo yeWeld | 24 | 150LB | 20 | A105 | 14 | IIFANGES ZETANKI | 16 |
| Into | Ubungakanani (Inch) | Iklasi yoXinzelelo | CS | Izinto eziphathekayo | Ubunzima (mm) | Indawo | Ubungakanani. |
| I-Flange, Intamo yeWeld | 24 | 400LB | 62 | I-ASTM A694 F70 | 7.92 | I-PSM1 | 2 |
| I-Flange, Intamo yeWeld | 20 | 400LB | 62 | I-ASTM A694 F70 | 7.14 | I-PSM1 | 6 |
| I-Flange, Intamo yeWeld | 24 | 400LB | 62 | I-ASTM A694 F70 | 7.92 | I-PSM1 | 4 |
| I-Flange, Intamo yeWeld | 20 | 400LB | 62 | I-ASTM A694 F70 | 7.14 | I-PSM1 | 10 |
| I-Flange, Intamo yeWeld | 12 | 400LB | 62 | I-ASTM A694 F70 | 4.78 | I-PSM1 | 4 |
| I-Flange, Intamo yeWeld | 4 | 400LB | 62 | I-ASTM A694 F70 | 4.78 | I-PSM1 | 4 |
| I-Flange, Intamo yeWeld | 24 | 400LB | 62 | I-ASTM A694 F70 | 7.92 | I-PSM1 | 25 |
| I-Flange, Intamo yeWeld | 4 | 400LB | 62 | I-ASTM A694 F70 | 4.78 | I-PSM1 | 16 |
| I-Flange, Intamo yeWeld | 24 | 400LB | 62 | I-ASTM A694 F70 | 7.92 | I-PSM1 | 2 |
| I-Flange, Intamo yeWeld | 20 | 400LB | 62 | I-ASTM A694 F70 | 7.14 | I-PSM1 | 6 |
| I-Flange, Intamo yeWeld | 24 | 400LB | 62 | I-ASTM A694 F70 | 7.92 | I-PSM1 | 4 |
| I-Flange, Intamo yeWeld | 20 | 400LB | 62 | I-ASTM A694 F70 | 7.14 | I-PSM1 | 10 |
| I-Flange, Intamo yeWeld | 12 | 400LB | 62 | I-ASTM A694 F70 | 4.78 | I-PSM1 | 4 |
| I-Flange, Intamo yeWeld | 24 | 400LB | 62 | I-ASTM A694 F70 | 7.92 | I-PSM1 | 25 |
| I-Flange, Intamo yeWeld | 4 | 400LB | 62 | I-ASTM A694 F70 | 4.78 | I-PSM1 | 16 |
| I-Flange, Intamo yeWeld | 10 | 300LB | 51 | I-ASTM A694 F65 | 4.78 | I-PSB1 | 2 |
| I-Flange, Intamo yeWeld | 6 | 300LB | 51 | I-ASTM A694 F65 | 4.78 | RABIGH | 4 |
| I-Flange, Intamo yeWeld | 4 | 300LB | 51 | I-ASTM A694 F65 | 4.78 | RABIGH | 4 |
| I-Flange, Intamo yeWeld | 18 | 300LB | 51 | I-ASTM A694 F65 | 4.78 | RABIGH | 2 |
| I-Flange, Intamo yeWeld | 8 | 300LB | 51 | I-ASTM A694 F65 | 4.78 | RABIGH | 2 |
| I-Flange, Intamo yeWeld | 8 | 300LB | 51 | I-ASTM A694 F65 | 4.78 | RABIGH | 2 |
Inkqubo yethu yokuqinisekisa umgangatho ibandakanya ulawulo lwenkqubo yezibalo kulo lonke ixesha lokuvelisa, kunye novavanyo lwebhetshi ukuqinisekisa ukuhambelana. Ukuhlolwa kokugqibela kubandakanya ukuvavanywa ngokubonakalayo kweziphene zomphezulu, ukuqinisekiswa kokuchaneka kobukhulu, kunye nokuqinisekiswa kophawu. Zonke iirekhodi zomgangatho zigcinwa ubuncinane iminyaka eli-10, ukuqinisekisa ukulandeleka okupheleleyo kunye nokuthobela imigangatho yomgangatho wamazwe ngamazwe.
FAQ
1. Ziziphi iintlobo ezahlukeneyo zezixhobo zokufaka iipayipi zentsimbi engagqwaliyo?
Impendulo: Izixhobo zombhobho wentsimbi engenasici ziquka izixhobo zombhobho wokuwelda ezingasemva, izixhobo zombhobho wokuwelda ezisokethini, izixhobo zombhobho ezinemisonto, iiflange, iivalvu nezinye iintlobo.
2. Yintoni umahluko phakathi kwezixhobo zombhobho wentsimbi engagqwaliyo ezingama-304 kunye ne-316?
A: Intsimbi engagqwaliyo engu-304 ifanelekile kwiintlobo ezininzi zezicelo kwaye inokumelana nokugqwala okuhle kakhulu. Intsimbi engagqwali engu-316, kwelinye icala, inokumelana nokugqwala okungcono kwiindawo ezinemingxunya kakhulu kwaye ifanelekile kwiintlobo zezixhobo zaselwandle nezekhemikhali.
3. Zithini iingenelo zokusebenzisa izixhobo zombhobho ezidityanisiweyo ezifakwe kwi-butt?
A: Izixhobo zokuwelda ezifakwe kwi-butt zibonelela ngamandla aphuculweyo, ukuthembeka, kunye noqhagamshelwano olungenawo amanzi. Zibonelela ngokumelana okuhle kakhulu nempembelelo kwaye zikhethwa kakhulu xa kusetyenziswa uxinzelelo oluphezulu kunye nobushushu obuphezulu.
4. Yintoni i-flange yokuwelda yempundu?
Impendulo: I-butt welding flange yi-pipe flange ene-hub ende ethambileyo kwaye idityaniswe kumbhobho. Inika utshintsho olugudileyo ukusuka kumbhobho ukuya kumbhobho ngamandla agqwesileyo kunye nokuthembeka.
5. Ngowuphi umgangatho wentsimbi engagqwaliyo oqhele ukusetyenziswa kwizixhobo zokufaka iipayipi?
A: Iindidi zentsimbi engatyiwayo ezingama-304, 316, 304L, 316L kunye ne-317 zisetyenziswa kakhulu kwizixhobo zemibhobho ngenxa yokumelana kwazo nokugqwala, ukuqina kunye nokuguquguquka kwazo.
6. Ngaba izixhobo zombhobho wentsimbi engagqwaliyo zingasetyenziswa kwiindawo ezinobushushu obuphezulu?
Impendulo: Ewe, izixhobo zentsimbi engagqwaliyo zifanelekile ukusetyenziswa kubushushu obuphezulu. Nangona kunjalo, umgangatho wentsimbi engagqwaliyo esetyenzisiweyo kufuneka ukhethwe ngononophelo ngokusekelwe kwiimfuno ezithile zobushushu zesicelo.
7. Ngaba izixhobo zombhobho wentsimbi engagqwaliyo zifanelekile kwishishini lokutya neziselo?
Impendulo: Ewe, izixhobo zombhobho zentsimbi engagqwaliyo zisetyenziswa kakhulu kwishishini lokutya neziselo ngenxa yococeko lwazo, ukumelana nokugqwala, kunye nokugcinwa lula.
8. Yintoni umahluko phakathi kwezinto zokufakelwa ukuwelda zesokhethi kunye nezinto zokufakelwa ukuwelda zebutt?
Impendulo: Izixhobo zombhobho ezifakwe kwisokhethi zifaka umbhobho kwisokhethi zize zenze i-fillet welding ukuze zidibanise umbhobho. Izixhobo zombhobho ezifakwe kwi-butt weld, kwelinye icala, zifuna ukuba iziphelo zombhobho zibekwe zibe bhetyebhetye zize zifakwe kwi-weld.
9. Ngaba izixhobo zombhobho wentsimbi engagqwaliyo zinokuphinda zisetyenziswe?
A: Ewe, izixhobo zombhobho wentsimbi engagqwaliyo zinokuphinda zisetyenziswe kwakhona. Intsimbi engagqwaliyo yinto ehlala ixesha elide enokuphinda isetyenziswe kwaye isetyenziswe ngaphandle kokulahlekelwa ziimpawu zayo okanye umgangatho wayo.
10. Ziziphi iingenelo zokusebenzisa izixhobo zombhobho wentsimbi engagqwaliyo xa kuthelekiswa nezinye izinto?
A: Izixhobo zombhobho wentsimbi engagqwaliyo zibonelela ngeenzuzo ezininzi, ezinje ngokumelana nokugqwala okugqwesileyo, amandla aphezulu, ukuqina kunye neempawu zococeko. Azigcinwa kakuhle, zihlala ixesha elide kwaye zicocekile kwaye zibukeka zintle.
Izixhobo zokufaka iipayipi zizinto ezibalulekileyo kwinkqubo yokuhambisa iipayipi, ezisetyenziselwa ukunxibelelana, ukuqondisa kwenye indawo, ukuphambukisa, ukutshintsha ubungakanani, ukuvala okanye ukulawula ukuhamba kwamanzi. Zisetyenziswa kakhulu kwiindawo ezifana nokwakha, ishishini, amandla kunye neenkonzo zikamasipala.
Imisebenzi ephambili:Ingenza imisebenzi efana nokudibanisa imibhobho, ukutshintsha indlela yokuhamba kwayo, ukwahlula nokudibanisa ukuhamba kwayo, ukulungisa ububanzi bemibhobho, ukuvala imibhobho, ukulawula nokulawula.
Ububanzi besicelo:
- Ulwakhiwo lwamanzi kunye nemibhobho yamanzi:Iingqiniba zePVC kunye nee-PPR tris zisetyenziselwa iinethiwekhi zemibhobho yamanzi.
- Imibhobho yemizi-mveliso:Iiflange zentsimbi engenasici kunye neengqiniba zentsimbi ye-alloy zisetyenziselwa ukuthutha izixhobo zamakhemikhali.
- Uthutho lwamandla:Izixhobo zokufaka iipayipi zentsimbi ezinoxinzelelo oluphezulu zisetyenziswa kwimibhobho yeoyile negesi.
- I-HVAC (Ukufudumeza, Ukungenisa umoya, kunye ne-Air Conditioning):Izixhobo zombhobho wekopolo zisetyenziselwa ukudibanisa imibhobho yefriji, kwaye amalungu aguquguqukayo asetyenziselwa ukunciphisa ukungcangcazela.
- Ukunkcenkceshela kwezolimo:Izihlanganisi ezikhawulezayo zenza kube lula ukuhlanganiswa nokuqhekeka kweenkqubo zokunkcenkceshela izitshizi.
-
